Flat elevator cable

Place of Origin ：Shaanxi, China
Brand Name ：JSH
Model Number： Elevator Cable
Jacket： PVC/rubber
Application ：lift, Telescopic door, driving
Model Number ：TVV/TVVB/TVVBG/TVVBPG/Elevator Cable
Type： LOW VOLTAGE
Rated Temperature： -15C°- +110℃
Rated Voltage： 300V/500V
Size ：1.5-95mm2
Insulation： PVC
Certificate ：CCC ISO CE SAA
Color ：Customer’s Requirment

Send inquiry
Product Description

Flat elevator cable, especially TVVB cable, is a type of elevator specific flat cable. Its insulated cores are twisted and arranged in groups, and the conductors are mostly made of multiple strands of bare copper or tin plated copper wire. It has the characteristics of strong flexibility and long service life.

Structure:

Flat elevator cables are usually composed of cable conductors, insulation layers covering the conductors, low dielectric layers placed outside the insulation layers, and shielding layers. The conductor part adopts multi strand ultra-fine precision twisted oxygen free copper wire, which complies with relevant electrical standards. The insulation layer uses a special mixed PVC material to improve the electrical performance and mechanical strength of the cable.

Applications:
1. The cable use special structure design, long service life, to maximize the operational efficiency of elevator manufacturing
enterprises.
2. The cable can provide overall electrical control in suspension longer length case, at the same time under mechanical stress.
Properties: The outer sheath is extensively resistant to oil and cooling liquid.

Item TVVB/TVVBG Copper PVC insulated sheathed for elevator travel flat cable
Insulation Material PVC
Sheath Material PVC
Color Black, Grey, Orange or your request
Conductor Material Copper
Rated Voltage 300/500V,450/750V
MOQ Capacity 100 meters
Temperature Range -15℃~ +70℃
Certifications CCC,ISO9001,CE,UL,RoHS

Type Conductor
Section(mm2)		 Conductor
Construction(mm2)		 Overall diameter
Dia.(mm)		 70℃ Insulated Resister
(M Ω·KM)		 20℃ Conductor DC Resister
(Ω/KM)
TVVB 20×0.75 30/0.18 29.9×9.0 ≥0.011 ≤26.0
TVVB 24×0.75 30/0.18 30.5×9.1 ≥0.011 ≤26.0
TVVBG 2×1.0+TV(SYV75-4) 7/0.24+50/0.16 15.8×7.6 ≥0.010 ≤26.0
TVVB 20×0.75+(2×2)×0.75 30/0.18 44.2×9.1 ≥0.011 ≤26.0
TVVB 36×0.75+(2×2)×0.75 30/0.18 62×10.0 ≥0.011 ≤26.0
TVVB 48×0.75+(2×2)×0.75 30/0.18 68.5×10.0 ≥0.011 ≤26.0
TVVBG 30×0.75 30/0.18 53×8.6 ≥0.011 ≤26.0
TVVBG 36×0.75 30/0.18 54.0×9.5 ≥0.011 ≤26.0
TVVBG 40×0.75 30/0.18 58×8.2 ≥0.011 ≤26.0
TVVBG 42×0.75 30/0.18 66.6×9.7 ≥0.011 ≤26.0
TVVBG 48×0.75 30/0.18 67.2×9.5 ≥0.011 ≤26.0
TVVBG 60×0.75 30/0.18 80.0×9.5 ≥0.011 ≤26.0
TVVB 30×0.75 30/0.18 44.2×9.1 ≥0.011 ≤26.0
TVVB 36×0.75 30/0.18 42.5×9.0 ≥0.011 ≤26.0
TVVB 36×0.75 30/0.18 52.5×9.0 ≥0.011 ≤26.0
TVVB 42×0.75 30/0.18 54.1×9.7 ≥0.011 ≤26.0
TVVB 48×0.75 30/0.18 58.0×9.6 ≥0.011 ≤26.0

FACTORY SHOW

Our Certificates

Products Process

How We Started

1.UNDERSTAND CUSTOMER NEEDS

Determine the specifications, quality requirements, and quantity of cables that the customer needs. If the customer is not clear about their needs, we can also recommend corresponding cables based on their usage, application scenarios, and other issues for customers to choose from and clarify their needs.





2.OFFER
After the customer’s needs are determined, we will provide the bestquotation in a timely manner based on their actual situation.







3.NEGOTIATION
The client will conduct a careful comparison and evaluation, and then engage in discussions. We answer customer inquiries and strive to help them understand the features and advantages of the product, thereby increasing their trust and recognition of the product.







4.SIGNING THE CONTRACT
We will accurately fill in the contract text based on the specific product, price, delivery time, payment method, and other terms agreed upon with the customer, and ensure that both parties understand and confirm the contract.







5.DELIVERY OF GOODS

After the contract is signed, we will strictly produce according to the technical requirements of the contract and relevant national standards, comply with the delivery time, and deliver the goods to the customer in a timely manner.







6.AFTER SALES
After the customer receives the goods, we will regularly visit the customer to understand their usage of our products and whether they have encountered any problems. We will promptly solve the problem for the customer.







7.COMPANY PURPOSE
To seek development through quality, to seek market through reputation, and to cooperate with global customers for mutual benefit.





FAQ(Frequently Asked Questions)

1. The time you can get the quotation after the sending the inquiry

In the working time, our sales manager will send quotation to your email box within 1 or 2 hours. On the contrast, we will send you email within 12 hours. Therefore, email is needed to let us know, then we can contact with you.

2. For Sample

We can provide you the sample for free, if you want to check the cable, you can ask the sales manager.

3.Payment

Our payment term is usually T/T 30% in advanced, the balance before picking up the goods or L/C at sight

4. What is the package of the cable ?

The package is usually wooden drum or steel wooden drum or coil.also according to customer’s requirement. …… If you have any other question, you can send us inquiry, we will reply to you as soon as possible.
