H05RN-F/H07RN-F high flexibility rubber cable

Products Description

H05RN/H07RN-F high flexibility rubber cable, the cable conductor is made of multi strand fine twisted pure copper material, the insulation layer is made of ethylene propylene diene monomer (EPDM), and the sheath is made of chlorinated polyethylene rubber (CPE) or polyurethane (PUR) composite material. The rated voltage is 450/750V, and it is used in complex industrial environments and outdoor scenes. It has the characteristics of weather resistance, oil resistance, and mechanical stress resistance.

Products Parameter

Working Temperature

H07RN-F model rated voltage U0/U IS 450/750V

H05RN-F model rated voltage U0/U IS 300/500V

H03RN-F model rated voltage U0/U IS 300/500V

Long time allow working temperature of wire core cant be higher than 65℃

Use Of The Product

H05RN-F/H07RN-F Rubber Cable Core Characteristics

Environmental adaptability:weather resistance, UV resistance, ozone resistance, suitable for outdoor and harsh weather conditions.

Mechanical performance: high flexibility and can be freely twisted (such as in wind turbine cable scenarios); Small bending radius (5-10 times the outer diameter of the cable).

Protection ability: flame retardant, oil resistant, acid alkali resistant, and seawater corrosion resistant.

Certification standards: Passed VDE, CE and other certifications, compliant with RoHS environmental requirements.

H05RN-F/H07RN-F rubber cable application scenarios

Industrial equipment: power connections for mobile power banks, automated production lines, and large machinery such as cranes and elevators.

In the field of new energy: wind turbines (rotor connection, tower cross connection system).

Construction project: Temporary power supply on construction site, stage equipment, barracks, and fixed wiring in underground mines.

Special environment: coastal areas, high-altitude regions, and flammable and explosive places (requiring supporting protective measures).
